Alu 5083

Why Choose Marine Grade Aluminum 5083

Among the hull materials of speedboats, aluminum plates have sufficient strength and rigidity, while being able to reduce weight, resist seawater corrosion, and have good weldability. Marine grade aluminium 5083 for ship building can effectively reduce ship weight and increase ship speed.

With 5083 aluminum sheet replacing traditional steel ship, each ship can save about 8-100 tons of weight on average. Its application is not only limited to the hull and parts, but also includes furniture, cabinets and deck.

5083 aluminum plate has good anti-rust function and can adapt to the corrosion of marine climate. It is often used in some humid and marine environments. For boat building, there are mainly O, H111, H112, H116 and H321 tempers,especially 5083-H321 aluminum sheet.

Different tempers of 5083 Marine Ggrade Aluminum Plate

5083-h116 and 5083-H321 aluminum plates have better corrosion resistance and are more suitable for the underwater environment of the ocean than H111 and H112 temper. Although the temperature of 5083H116 and H321 aluminum sheets are slightly different in the production process, the corrosion resistance is significantly better than other tempers.

Applications of 5083 Aluminum Plate

  • 5083 marine aluminum plate is a typical Al-Mg-Si alloy with high corrosion and rust resistance. The underwater part of the hull, especially in the sea water, must be able to resist the corrosion of seawater. The most commonly used ones are 5083-H116 and 5083-H321 aluminum sheets.

  • The keel is a longitudinal member connecting the bow post and the stern post in the center of the base of the hull. 5083 aluminum sheet is the common choice.

  • 5083 aluminum plate is mainly used in the deck, engine pedestal, side of the ship, and the outer plate of the bottom of the ship.

  • 5083-H116 aluminum sheet is also used in transportation field, such as automobile and aircraft fuel tank, etc.

Specification of 5083 Marine Aluminum Sheet

Chemical composition

Alloy

Si

Fe

Cu

Mn

Mg

Cr

Zn

Ti

Zr

Unit

5083

0.4

0.4

0.1

0.40-1.00

4.00-4.90

0.05-0.25

0.25

0.15

-

Wt%


Mechanical properties

Alloy

Temper

Rm(Mpa)

Tensile strength

Rp0.2(MPa)

Yield strength

Elongation

A(%)

Exfoliation

corrosion

Intergranular corrosion

Mg/cm2

Certification

5083

O/H111/H112

275

125

16

-

-

DNV, GL, ABS, CCS, BV, LR

H116

305

215

10

PB

15

H321

305-385

215-295

12

Size

Alloy

Temper

Thickness(mm)

Widthmm

Length(mm)

5083

O,H12,H14,

H16,H18,H19,

H22,H24,H26,

H28,H32,H34

H36,H38,H111,

H112,H114,H 116,H321

3-50 mm

2000 mm or customized

6000/8000/9000/12000mm or customized



Advantages of Aluminum 5083 for Ship Building

1. 5083 aluminum plate is of low density, contributing to the light weight of the ships and less fuel consumption. It can also improve the the length-to-width ratio of the ship and stability,which makes the ship easier to maneuver.

2. 5083 aluminum plate is of extremely good corrosion resistance, reducing maintenance costs such as oiling.

3. It has good processing and forming performance, which is easy to be processed in various forms such as cutting, stamping, cold bending, forming and cutting. This is helpful for the light weight and reasonable structure of the ships.

4. 5083 aluminum sheet is of good welding performance, reducing numbers of welds.

5083 Aluminum Plate Stock

Alloy

Temper

Thickness(mm)

Width(mm)

Length(mm)

5083

H116

4.0

2000

6000

5083

H116

5.0

2000

6000

5083

H116

6.0

2000

6000

5083

H116

8.0

2000

6000

5083

H116

10

2000

6000

5083

H116

12

2000

6000

5083

H116

14

2000

6000

5083

H116

20

2000

6000

5083

H116

25

2000

6000

Why Choose Haomei Aluminum

  • During the production process, a small amount of Be is added to the 5083 aluminum plate to reduce the cracking tendency of the ingot and improve the surface quality of the rolled plate.

  • 5083 marine aluminum plate is certificated by DNV and CSS.

  • 5083 aluminum plate has no oil spots, no scratches, no rolling marks, no burrs and neat trimming.

  • With strong production capacity, we can take orders of 8-5000 tons with 7-35 days delivery. We can also offer you best aluminum 5083 price based on our strong supply capacity.

  • Our 5083 aluminum plate can reach 2650 mm wide and 600 mm thick.
