What Are Marine Aluminum Plate Grades
5xxx series aluminium plate grades are non-heat-treatable aluminum alloys. They are widely used in transportation fields such as automobiles and ships because of their light weight, high strength and good corrosion resistance.
The most common is 5083 aluminum plate, which is an aluminum-magnesium alloy with low density, high toughness, high corrosion resistance and weldability. It is mainly used on the hull. It can adapt well to the harsh marine environment.
The use of aluminum alloy profiles in ship-type transportation vehicles began in the 1790s, and it has a history of more than 100 years. 6061 aluminum is a precipitation hardening alloy containing magnesium and silicon, which is used to manufacture marine accessories and hardware.
6082 aluminum alloy belongs to the aluminum-magnesium-silicon series and can be heat-treated to strengthen deformation aluminum alloy. It has medium strength, low density, good corrosion resistance, good processing performance and welding performance. It can be used to manufacture high-speed ship hulls, large marine welded structures and marine parts.
Alloy | Rm(MPa) | Rp0.2(MPa) | Elongation(%) | HBS10/500 | Fatigue strength(MPa) |
5052-O 5052-H32 5052-H34 5052-H36 5052-H38 | 195 230 260 275 290 | 90 195 215 240 255 | 25 12 10 8 7 | 47 60 68 73 77 | 110 115 125 130 140 |
5083-O 5083-H321 5083-H116 | 290 315 315 | 145 230 230 | 16 12 10 | 13.3 14 14
| 130 |
5086-O 5086-H32 5086-H116 5086-H34 5086-H112 | 260 290 290 325 270 | 115 205 205 255 130 | 22 12 12 10 14 | 12.6 13.3 13.3 14.3 12.9 | 150 |
6061-O 6061-T4/T451 6061-T651 | 125 240 310 | 55 145 275 | 25 22 12 | 30 65 95 | 60 95 95 |
Haomei Aluminum 5xxx and 6xxxaluminum sheets and profiles all get the certification of the main Classification Societies like DNV, ABS, LR, RINA, CCS,etc. Welcome to inquire aluminium sheet cost from us.
