5052VS6061 Aluminum Sheet
The difference between 5052 aluminum plate and 6061 sheet mainly comes from the difference in heat treatment process, shown in performance and use. There are similarities in materials. So what is the difference between the two?
Different alloy elements
The alloy element of 5052 is magnesium, and the alloy element of 6061 contains silicon in addition to magnesium. Furthermore, the processing status is also different. In addition to the fact that both 6061 aluminum plates and 5052 aluminum plates have the O temper, 6061 aluminum plates are generally in the T6 and T651 tempers and the tempers of 5052 aluminum sheet are H12, H24 and H32.
Mechanical properties
Al 5052’s tensile strength is ≦225, elongation is ≧10; Al 6061’s tensile strength is ≧180, yield strength is ≧ 110 and elongation is ≧14.
Different properties and applications
5052 aluminum properties are also good. It has good fatigue resistance, high plasticity and corrosion resistance. It cannot be strengthened by heat treatment. It has good plasticity during semi-cold work hardening and low plasticity during cold work hardening. It is widely used in various industrial structural parts that require certain strength and high corrosion resistance. 6061 aluminum plates are mostly used in places with high strength requirements.
Different specifications
5052 aluminum plate:
Thickness (mm): 0.15-600
Width (mm): 20-2600
Length (mm): 500-16000
6061 aluminum plate:
Thickness (mm): 0.3-500
Width (mm): 500-2800
Length (mm): 500-16000
Different prices
The price difference between 5052 and 6061 aluminum sheet is mainly due to the proportion of their alloy components. Because of the complexity of the process and the different performance requirements of the process, the price of 6061 aluminum plate is naturally much higher than that of 5052 aluminum sheet.
5052 aluminum sheet belongs to the 5 series aluminum alloys, while 6061 sheet belongs to the more expensive one among the 6xxx aluminum plates. Based on the comparison of the alloy conditions of the two in 2022, we can judge from this situation that the processing fee difference between the two is 500-800 dollars.
In the future, the price gap between the two should further widen, because 5052 aluminum plates are gradually being used in various industries, and everyone is considering choosing lighter aluminum plate alloys to replace iron, stainless steel and copper. etc.
